Temperature (solid) (° C)
exterior view 1 : contour line
Temper ature ambient:25° C
30W/m test
Information
-
①Profile
-
② Power supply
-
③ End cap waterproof ring
-
④ Heat sink
-
⑤ PC end cap
-
⑥ Waterproof PG
-
⑦ Lighting source
-
⑧ Reflective paper
-
⑨ Screw
-
Pendant
-
Cover
Heated structure
Downloads
Catalogue pageProducts
Order Guide
| Name | Order code | Discription | Size | Color | Picture |
| LS4265S-III-W kit | LS4265S-III-W001 | Profile+heat sink+cover | 42*65*2500mm | silver/black/whit（ral9016） |  |
| Profile | LS4265S-III-WPRO | AL 6063-T5 | 2500mm | silver/black/whit（ral9016） |  |
| Heat sink | LS4265S-III-WHSK | AL 6063-TS | 2500mm | silve/b1ack/White(ral9016) |  |
| Anti-glare film | LSXXXXFGP | Increase efficacy by 20% | 2500mm | White |  |
| Aluminum cover | LS4265S-III-NAIM | aluminum cover | 2500mm | silver/black/white（ral9016） |  |
| Black cover | LS4265S-III-NBAK | PC | 2500mm | black |  |
| Cover | LS4265S-III-NCOV | PC | 2500mm | Diffuser（white） |  |
| Flexible cover | LS4265S-III-NC22 | PC | 20m | Diffuser（white） |  |
End cap | LS4265S-III-W002A | PC | 42*65mm | silver/black/white (ral9016) |  |
| End cap kit | LS4265S-III-W002B | PC | 42*65mm | silver/black/white (ral9016) |    |
Silicone band | LSXXXXGJT | ∅=2.5mm | - | Transparent |  |
PCB | NJG-499-12C10B-2 | Lumen:3000LM P: 36W/m,Ra>80 | Width: 23mm | |  |
Terminal box | LSXXXXSJXH | Anti-fire PC | 80*80*38mm | Silver |  |
| Pendant kit | l.SXXXXSDZJ | Steel wire、CDpper | 2000mm | silver |  |
| Pendant kit | l.SXXXXSDZJ-01 | Steel wire、Opper | 2000mm | silver |  |
| Tenninal box | LSXXXXSJXH-01 | Iron | Φ130mm*H38mm | silver/black/white (ral9016) |  |
| Tenninal box | l.SXXXXSJXH-02 | Iron | Φ130mm*H38mm | silver/black/white (ral9016) |  |
| Tenninal box | l.SXXXXSJXH-03 | Iron | Φ130mm*H38mm | silver/black/white (ral9016) |  |
Embed buckle | LSXXXXSNQB | Stainless steel | - | Silver |  |
Surface mounted clip | LSXXXXSPJBM | Stainless steel | - | unpainted stainless steel |  |
Wire protection | LSXXXXHXB | PWB:3X4mm | - | - |  |
